Door Sensor Window Sensor Smart Home Wireless Door Detector

$17.00 USD

Sale Sold out

Shipping calculated at checkout.

Type WiFi Door Sensor

Quantity

Description

Upgrade your home security and automation with this Smart Home Wireless Door and Window Sensor. Designed to enhance the safety of your home, this sensor detects the opening and closing of doors and windows, providing instant alerts to your smartphone. With seamless integration into your existing smart home system, it allows you to automate various tasks, such as turning on lights or adjusting the thermostat when a door or window is opened. Perfect for securing entry points in your home, this wireless sensor offers peace of mind and adds a layer of smart functionality to your daily routine.

Specification

Input voltage:3V LR03

Quiescent Current:≤45uA

Alarm Current:≤130mA

Low power under voltage:≤2.4V

WiFi:802.11 b/g/n

Magnetic control distance:≥15mm

Battery: DC 3V LR03(AAA battery,not included)

Alarm mode: mobile phone APP notification push(Smart Life/Tuya Smart)

Size: Main body: 68*23*19mm

Permanent magnet: 43*10*14mm

Choice: yes

semi_Choice: yes

Features

【2.4GHz WiFi One-Key Connect Easy Setup】 Do not need a home gateway, you can easily achieve the intelligent control of home appliances, simple operation, easy to use 2.4G Hz protocol is more stable, faster and more convenient

【Detect door/window status 】When the door/window is opened or closed, the device triggers and push notification to the phone.

【Linked alarm with more sensors】 Set up the scene: away from home mode, if someone breaks in, the device triggers and push notification to the phone., and the IP camera (not included) will shoot the video. When someone opens the door, the light turns on automatically.

【APP Remote Control 】Home is in the hands, whenever and wherever

【Easy to install】Small size, easy to install Adhesive installation, can be flexibly placed in various doors, windows, drawers, etc, without destroying the appearance and structure of the original furniture

Product Extra Detail

View full details

Nice device, but in my case the operating distance was quite low.
The sensor should be mounted as shown in Fig. 1 with the two marks facing each other. In fact, as shown in Fig. 2, the sensor on the PCB is centrally positioned on the side with the mark. But I've seen that the sensor's sensitivity was low and I had to hold the magnet very close to the sensor.
I solved it this way: open the magnet's container and rotate the magnet by 90 degrees.
In the original position (Fig. 3) it fit loosely in the housing, while after rotating (fig. 4) it fits perfectly. In my case (tested with two sensors) the working distance doubled. (I'm almost starting to suspect that the magnets were mounted incorrectly at the factory...)
